The Specifications of Chiler Water Bath is as below
| Rotary Evaporator Model | Chiller MODEL | Temp. range | Cooling Capacity | KW | Tank Capacity | Process Pump | DRIVE MOTOR REQD H. P. | |
|---|---|---|---|---|---|---|---|---|
| Ton of Refrigeration | Kcal/Hour | |||||||
| GRFE 5 | FRAC 600 | +5°C to +25°C | 0.5 | 1500 | 1.7 | 20 | 35 LPM @ 0.3 Bar | 0.25 |
| GRFE 20 /GRFE 10 | FRAC 1000 | +5°C to +25°C | 1 | 3000 | 3.5 | 40 | 50 LPM @1.2 Bar | 0.5 |
| GRFE 50 | FRAC 2000 3P | +5°C to +25°C | 2 | 6000 | 7.0 | 75 | 50 LPM @1.2 Bar | 0.5 |
| GRFE 100 | FRAC 5000 | +5°C to +25°C | 5 | 15000 | 17.5 | 150 | 100 LPM | 1 |
